Technical data
| Size | S | M | L |
|
Hygiene opening adjustable Level 1 Level 2 Level 3 |
48 mm 78mm 108 mm |
58 mm 88 mm 118 mm |
68 mm 98 mm 128 mm |
|---|---|---|---|
| Total width max. from handle to handle |
502 mm | 512 mm | 522 mm |
| Seat height | 460 mm | 500 mm | 540 mm |
| Height with backrest | 768 mm | 808 mm | 848 mm |
| Wheel spacing | 301 mm | 311 mm | 321 mm |
| Turning circle - space requirement | 470 mm | 480 mm | 490 mm |
| Load capacity / max. user weight | 150 kg | 150 kg | 150 kg |
| Weight shower stool stainless steel | 3.8 kg | 4 kg | 4.2 kg |
| Weight Shower stool matt black | 4.6 kg | 4.8 kg | 5.1 kg |
| Weight backrest | 1.8 kg | 1.8 kg | 1.8 kg |
KTL and powder coating
Cathodic dip painting (KTL) is an electrochemical process in which the spa is coated in a bath of aqueous dip paint under a direct voltage of 3,000 amperes and 220 to 290 volts.
In powder coating, paint powder is electrostatically charged and applied to the material with a powder gun. A prerequisite is that the material to be coated is electrically conductive, the spa is made of steel. The paint coating is then baked in the curing oven at a temperature of between 140° and 200° C. The material is thoroughly derusted, degreased, blasted etc. in advance. - For the quality of the powder coating, it is very important to reserve the surface.
